智能摘要 AI
Harbor是一个企业级Docker私有仓库解决方案，通过Docker-compose管理容器。安装时需根据官方指南配置harbor.yml，确保使用自签名证书、定期备份数据卷以及LDAP整合配置。所有容器默认设置为`restart: always`，但手动停止后不会重启。作者遇到部分容器未自动重启的问题，通过将Harbor配置为systemd服务解决了此问题。最终重启服务器后，所有容器均正常启动并保持健康状态。
Harbor是一个企业 Docker私人仓储的工程，当Docker-compose开始时， Harbor自身包括许多Docker-compose，它们通过Docker-compose来控制 containers的相关。
安装
具体的设置请参阅正式文件： Harbor-部署和配置指南。yml在我们对 harbor. yml进行了一些修改时，有以下几点需要考虑：
- 当您在 https中创建您自己的凭证并将其配置到 harbor. yml中。
- 客户机还必须将您所产生的凭证安装起来，不然就会出错。（所以一定要备份凭证）
- Docker – Using self-signed certificates
- 可以将data_volume作为/data/harbor，并将其作为一个周期性的备份。（也可以将 harbor安装到新设备上，并定时进行 Harbor的存储系统。）
- 对于企业来说，也有必要对 ldap整合确认进行配置。
然后，通过命令（sudo./install. s）来设置 harbor （看来一定要用 sudo，原因是所有的配置都是 root，并且有非常苛刻的特权。）当安装完毕时， harbor将会被自动地引导。
自动启动
查看 harbor 目录下的 docker-compose.yml 会发现，所有的 containers 都配置了 restart: always：
version: '2.3'
services:
log:
image: goharbor/harbor-log:v1.8.1
container_name: harbor-log
restart: always
dns_search: .
# ......
registry:
image: goharbor/registry-photon:v2.7.1-patch-2819-v1.8.1
container_name: registry
restart: always
# ......
这表示所有的容器在意外关闭后都会自动重启，比如 docker 重启或服务器重启。（手动 stop 不会自动重启）
但是我在手动运行 docker-compose up -d，然后重启服务器后，发现有几个 container 并没有自动重启：
[ryan@ryan-pc ~]$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
f30d802002a4 goharbor/nginx-photon:v1.8.1 "nginx -g 'daemon of…" 13 hours ago Exited (128) 27 minutes ago 0.0.0.0:80->80/tcp nginx
21472ce8a993 goharbor/harbor-portal:v1.8.1 "nginx -g 'daemon of…" 13 hours ago Exited (128) 27 minutes ago 80/tcp harbor-portal
5d866bb17c58 goharbor/harbor-jobservice:v1.8.1 "/harbor/start.sh" 13 hours ago Exited (137) 26 minutes ago harbor-jobservice
0cf0f93b5a87 goharbor/harbor-core:v1.8.1 "/harbor/start.sh" 13 hours ago Up 11 seconds (health: starting) harbor-core
cba280d9b945 goharbor/redis-photon:v1.8.1 "docker-entrypoint.s…" 13 hours ago Exited (137) 26 minutes ago 6379/tcp redis
473e46d1f746 goharbor/harbor-registryctl:v1.8.1 "/harbor/start.sh" 13 hours ago Up 11 seconds (health: starting) registryctl
51f105f1691d goharbor/registry-photon:v2.7.1-patch-2819-v1.8.1 "/entrypoint.sh /etc…" 13 hours ago Exited (137) 26 minutes ago 5000/tcp registry
c41594ec7779 goharbor/harbor-db:v1.8.1 "/entrypoint.sh post…" 13 hours ago Up 11 seconds (health: starting) 5432/tcp harbor-db
713bd4961772 goharbor/harbor-log:v1.8.1 "/bin/sh -c /usr/loc…" 13 hours ago Up 11 seconds (health: starting) 127.0.0.1:1514->10514/tcp harbor-log
可以看到下列五个容器都处于 Exited 状态：
goharbor/nginx-photon:v1.8.1
goharbor/harbor-portal:v1.8.1
goharbor/harbor-jobservice:v1.8.1
goharbor/redis-photon:v1.8.1
goharbor/registry-photon:v2.7.1-patch-2819-v1.8.1搜索发现有人提过这个 issue: https://github.com/goharbor/harbor/issues/7008
于是尝试将 harbor 配成 systemd 的 service，添加配置文件 /usr/lib/systemd/system/harbor.service，内容如下：
[Unit]
Description=Harbor
After=docker.service systemd-networkd.service systemd-resolved.service
Requires=docker.service
Documentation=http://github.com/vmware/harbor
[Service]
Type=simple
Restart=on-failure
RestartSec=5
ExecStart=/usr/local/bin/docker-compose -f {{ harbor_install_path }}/harbor/docker-compose.yml up
ExecStop=/usr/local/bin/docker-compose -f {{ harbor_install_path }}/harbor/docker-compose.yml down
[Install]
WantedBy=multi-user.target
其中 {{ harbor_install_path }} 换成自己的 harbor 安装路径。 还有 docker-compose 的绝对路径，请通过 which docker-compose 查看。
然后启动该项服务：
sudo systemctl enable harbor
sudo systemctl start harbor
现在查看下 harbor.service 的情况：
● harbor.service - Harbor
Loaded: loaded (/usr/lib/systemd/system/harbor.service; enabled; vendor preset: disabled)
Active: active (running) since Sun 2019-07-07 12:54:27 CST; 2min 4s ago
Docs: http://github.com/vmware/harbor
Main PID: 9734 (docker-compose)
Tasks: 11 (limit: 4915)
Memory: 35.7M
CGroup: /system.slice/harbor.service
└─9734 /usr/bin/python /usr/bin/docker-compose -f /home/ryan/harbor/docker-compose.yml up
7月 07 12:54:30 ryan-pc docker-compose[9734]: [128B blob data]
7月 07 12:54:31 ryan-pc docker-compose[9734]: [167B blob data]
7月 07 12:54:31 ryan-pc docker-compose[9734]: registryctl | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: registry | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: harbor-db | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: redis | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: harbor-core | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: harbor-jobservice | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: harbor-portal | WARNING: no logs are available with the 'syslog' log driver
7月 07 12:54:31 ryan-pc docker-compose[9734]: nginx | WARNING: no logs are available with the 'syslog' log driver
重启服务器再确认，发现 harbor 容器组终于全部 up 了：
[ryan@ryan-pc ~]$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
90943210e354 goharbor/nginx-photon:v1.8.1 "nginx -g 'daemon of…" 37 seconds ago Up 35 seconds (healthy) 0.0.0.0:80->80/tcp nginx
bc70706d7b5f goharbor/harbor-portal:v1.8.1 "nginx -g 'daemon of…" 38 seconds ago Up 36 seconds (healthy) 80/tcp harbor-portal
54e132bd1a10 goharbor/harbor-jobservice:v1.8.1 "/harbor/start.sh" 38 seconds ago Up 36 seconds harbor-jobservice
28ada4a941ee goharbor/harbor-core:v1.8.1 "/harbor/start.sh" 39 seconds ago Up 37 seconds (healthy) harbor-core
de44686f7e72 goharbor/registry-photon:v2.7.1-patch-2819-v1.8.1 "/entrypoint.sh /etc…" 39 seconds ago Up 38 seconds (healthy) 5000/tcp registry
e5efdae34c13 goharbor/harbor-db:v1.8.1 "/entrypoint.sh post…" 39 seconds ago Up 38 seconds (healthy) 5432/tcp harbor-db
a5fe52e1f184 goharbor/harbor-registryctl:v1.8.1 "/harbor/start.sh" 39 seconds ago Up 38 seconds (healthy) registryctl
4a74b5f3499a goharbor/redis-photon:v1.8.1 "docker-entrypoint.s…" 39 seconds ago Up 38 seconds 6379/tcp redis
677fd84d0a70 goharbor/harbor-log:v1.8.1 "/bin/sh -c /usr/loc…" 40 seconds ago Up 39 seconds (healthy) 127.0.0.1:1514->10514/tcp harbor-log
